Series 6 wall-mounted cooker hood 80 cm , BlackDWK81AN60
DWK81AN60
1 / 0
Series 6 wall-mounted cooker hood 80 cm , BlackDWK81AN60
DWK81AN60
Datasheet
Find a local Dealer
Find a local dealer in your vicinity
Series 6 wall-mounted cooker hood 80 cm , BlackDWK81AN60
DWK81AN60
Datasheet
Find a local Dealer
Find a local dealer in your vicinity
Technical Overview
Installation typology
Wall-mounted
Width
80 cm
Hob-based hood control
Yes
Noise level
51 dB(A) re 1 pW
PerfectAir
No
Operating Mode
Exhaust / Recirculation (Accessory available separately)
Max. air extraction
432 m³/h
Boost position air extraction
915 m³/h
Awards
Specifications
Width
80 cm
Colour
Black
Installation typology
Wall-mounted
Operating Mode
Exhaust / Recirculation (Accessory available separately)
Total power of the motors
190 W
Type of control setting and signalling devices
touch control, Via app
Number of speed settings
3-stages + intensive setting
Max. air extraction
432 m³/h
Boost position air extraction
915 m³/h
Sound power at max. speed (2010/30/EC)
51 dB
Sound power boost (2010/30/EC)
68 dB
Max. air recirculation
438 m³/h
Boost position output recirculating
886 m³/h
Sound power at max. speed (recirculation)
60 dB
Sound power boost (recirculation)
78 dB
Grease filter material
Washable stainless steel
Energy efficiency class
A+
Total annual energy consumption
35.5 kWh/annum
Included user manuals
[DE, ES, FR, PT]
Voltage
220-240 V
Height of the appliance
450 mm
Width of the appliance
790 mm
Depth of the product
433 mm
Dimensions of the packed product (HxWxD)
770x730x1230 mm
Height of the chimney
420-663/457-750 mm
Minimum distance above an electric hob
450 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
150 / 120 mm
No-return airflow flap
No
Length electrical supply cord
130 cm
Net weight
21.9 kg
Handle bar
Not applicable
Appliance height exhaust air max
1098 mm
Appliance height exhaust air min
855 mm
Appliance height recirculating max
1185 mm
Appliance height recirculating min
892 mm
1 / 0
PerfectAir
No
Extremely quiet and powerful brushless BLDC motor
Yes
Extremely quiet
Yes
Clean filter reminders
No
Boost position
Yes
Delay Shut off modes
Yes
Remote control
No
Type of lamps used
LED
Number of lights
2
Total power of the lamps
GENERAL.N_A W
Total luminance
422 lux
Color temperature
Neutral (3.500 K)
Illumination type softlight
Yes
Light color tunable by Home Connect
Yes
Ambient light
No
Connected appliances with Home Connect
Yes
Home Connect Features
iService Remote, Remote Monitoring and Control
Hob-based hood control
Yes
Smart Hood Automatic
Yes, with all hobs with same feature and connected Home Connect account
